Deep Groove Sealed Ball Bearings , Imperial Deep Groove Ball Bearings 16007-2Z 35X62X9MM

  • Deep Groove Sealed Ball Bearings , Imperial Deep Groove Ball Bearings 16007-2Z 35X62X9MM
  • Deep Groove Sealed Ball Bearings , Imperial Deep Groove Ball Bearings 16007-2Z 35X62X9MM
  • Deep Groove Sealed Ball Bearings , Imperial Deep Groove Ball Bearings 16007-2Z 35X62X9MM
  • Deep Groove Sealed Ball Bearings , Imperial Deep Groove Ball Bearings 16007-2Z 35X62X9MM
  • Deep Groove Sealed Ball Bearings , Imperial Deep Groove Ball Bearings 16007-2Z 35X62X9MM
  • Deep Groove Sealed Ball Bearings , Imperial Deep Groove Ball Bearings 16007-2Z 35X62X9MM
Place of Origin: Japan
Brand Name: NSK
Certification: ISO9001:2008,CE
Model Number: 16007-2Z
Minimum Order Quantity: 1pc
Price: USD0.1/PC
Packaging Details: NEUTRAL PACKAGE
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 10000PCS PER MONTH
Product Details
Material: Chrome Steel Quality Standard: ISO9001:2008
Clearance: C2,C0,c3 Precision Rating: P6
High Light:

v groove ball bearing

,

u groove ball bearing
Leave a Message
Product Description

Deep Groove sealed Ball Bearing 16007-2Z

Deep groove ball bearings are one kind of radial bearings widely used. They are simple in structure non-separable cheap in its price. In addition they require little maintenance in service as well as are capable to be operated at high speeds.



Both the inner and outer ring of single roe deep groove ball bearings have a deep groove raceway in addition the goods sealing quality between raceway and ball can make bearings carry radial loads as well as certain axial loads. After the radial clearance is increased properly axial load carrying capacity will be improved accordingly. Thats the reason why it can replace high speed angular contact ball bearings in some cases.



Deep Groove Ball Bearings use is very widespread. In addition to open type bearings, these bearings often have steel shields or rubber seals installed on one or both sides and are pre-lubricated with grease. Also, snap rings are sometimes used on the periphery. As to cages, pressed steel ones are the most common. For big deep groove ball bearings, machined brass cages are used. Machined cages are also used for high speed applications.



They can be classified as: open, shielded, or sealed. “WJY” bearing can supply deep groove ball bearing with metric size, inch size, and with flange, ceramic, stainless steel deep groove ball bearings, double-row deep groove ball bearings, they are widely used in universal motor, household appliances, instrument, internal-combustion engine, Construction Machinery, Railway Vehicle, Loading and Unloading Machinery, Agricultural Machinery etc



Features:

1: Can withstand radial load and bidirectional axial load
2: Suitable for high-speed rotation and require low noise, low vibration of the occasion
3: With a steel plate dust cover or rubber seal seal bearing in advance filled with the right amount of grease;



Bearing Model 16007-2Z
Type Deep groove ball bearing
Bore Size (mm) 35
Outside Diameter (mm) 62
Width (mm) 9
Mass (kg) 0.107
Material Chrome Steel, Carbon steel, Stainless steel
Cage Material Nylon
Number of Row Single Row
Precision Rating P5. P6
Basic Dynamic Load Rating (Cr) 23.4 kN
Basic Static Load Rating (Cor) 11.6 kN
Limiting Speed 7500 r/min


Packing & Delivery:

Single box--Paper carton--Wooden case
3-5 days upon your confirmation of the order

Specifications:

1. High precision bearings
2. ISO standard
3. Material:Gcr15 High- carbon chrome steel

Adavantages:

1. Fast delivery
2. Competitive price
3. High performance
4. Perfect packing and aftermarket service
5. Flexiable paymnet terms
6. Famous brand all over the worl
Deep Groove Sealed Ball Bearings , Imperial Deep Groove Ball Bearings 16007-2Z 35X62X9MM 0


Bearing No. Inner diameter Outer diameter Width Rated load Steel ball parameters Limit speed(RPM) Weight
Dynamic Static No. Size Grease Oil
d D B Cr Cor mm r/min r/min KG
16001 12 28 7 5.1 2.4 8 4.763 26000 3000 0.019
16002 15 32 8 5.6 2.8 9 4.763 22000 26000 0.025
16003 17 35 8 6.8 3.35 10 4.763 20000 24000 0.032
16004 20 42 8 7.9 4.5 10 5.556 18000 21000 0.051
16005 25 47 8 8.35 5.1 12 5.556 15000 18000 0.059
16006 30 55 9 11.2 7.4 12 6.35 13000 15000 0.091
16007 35 62 9 11.7 8.2 14 6.35 12000 14000 0.107
16008 40 68 9 12.6 9.65 15 6.35 10000 12000 0.125
16009 45 75 10 12.9 10.5 16 6.35 9200 11000 0.171
16010 50 80 10 13.2 11.3 16 7.144 8400 9800 0.18
16011 55 90 11 18.6 15.3 16 7.938 7700 9000 0.258
16012 60 95 11 20 17.5 18 7.144 7000 8300 0.283
16013 65 100 11 20.5 18.7 20 7.144 6500 7700 0.307
16014 70 110 13 24.4 22.6 15 9.525 6100 7100 0.441
16015 75 115 13 25 24 16 9.525 5700 6700 0.464
16016 80 125 14 25.4 25.1 15 11.112 5300 6200 0.597
16017 85 130 14 25.9 26.2 16 11.112 5000 5900 0.626
16018 90 140 16 33.5 33.5 15 12.7 4700 5600 0.848
.
.
.		 　 　 　 　 　 　 　 　 　 　
16052 260 400 44 235 310 　 　 1100 1500 22.5
