16011-2Z Flanged Deep Groove Ball Bearings , Deep Sealed Ball Bearings
Name: | Flanged Deep Groove Ball Bearings | Quality Standard: | ISO9001:2008 |
---|---|---|---|
Clearance: | C2,C0,c3 | Precision Rating: | P6 |
High Light: | v groove ball bearing,u groove ball bearing |
Deep Groove sealed Ball Bearing 16011-2Z
Deep groove ball bearings are one kind of radial bearings widely used. They are simple in structure non-separable cheap in its price. In addition they require little maintenance in service as well as are capable to be operated at high speeds.
Both the inner and outer ring of single roe deep groove ball bearings have a deep groove raceway in addition the goods sealing quality between raceway and ball can make bearings carry radial loads as well as certain axial loads. After the radial clearance is increased properly axial load carrying capacity will be improved accordingly. Thats the reason why it can replace high speed angular contact ball bearings in some cases.
Deep Groove Ball Bearing Application:
This bearings can be used: After ing equipment, machine tool spindles, plug-in, ordinary type cooling tower, resistance welding machine, aging furnace, hobbing machine, environmental protection equipment, whirlpool pump, ceramics engraving machine, metal packaging machinery, fishing machinery, high pressure reactor, offset printing, aerospace, rubber granulating machine, plastic machine, chip conveyor, and so on purpose.
Features:
1: Can withstand radial load and bidirectional axial load
2: Suitable for high-speed rotation and require low noise, low vibration of the occasion
3: With a steel plate dust cover or rubber seal seal bearing in advance filled with the right amount of grease;
Bearing Model | 16011-2Z |
Type | Flanged Deep Groove Ball Bearings |
Bore Size (mm) | 55 |
Outside Diameter (mm) | 90 |
Width (mm) | 11 |
Mass (kg) | 0.258 |
Material | Chrome Steel, Carbon steel, Stainless steel |
Cage Material | Nylon |
Number of Row | Single Row |
Precision Rating | P5. P6 |
Basic Dynamic Load Rating (Cr) | 23.4 kN |
Basic Static Load Rating (Cor) | 11.6 kN |
Limiting Speed | 7500 r/min |
Transportation:
1. Less than 45 KGS, we will send by express. (Door to Door, Convenient)
2. Between 45 - 200 KGS, we will send by air transport. (Fastest and safest, but expensive )
3. More than 200 KGS, we will send by sea. (Cheapest and usual)
Payment:
1. TT. 30% payment in advance as deposit, balance before delivery.
2. L/C at sight. (high bank charges, not suggest , but acceptable )
3. 100% Western Union in advance. (specially for air shipment or small amount)
Specifications:
1. High precision bearings
2. ISO standard
3. Material:Gcr15 High- carbon chrome steel
Adavantages:
1. Fast delivery
2. Competitive price
3. High performance
4. Perfect packing and aftermarket service
5. Flexiable paymnet terms
6. Famous brand all over the worl
Bearing No. | Inner diameter | Outer diameter | Width | Rated load | Steel ball parameters | Limit speed(RPM) | Weight | |||
Dynamic | Static | No. | Size | Grease | Oil | |||||
d | D | B | Cr | Cor | mm | r/min | r/min | KG | ||
16001 | 12 | 28 | 7 | 5.1 | 2.4 | 8 | 4.763 | 26000 | 3000 | 0.019 |
16002 | 15 | 32 | 8 | 5.6 | 2.8 | 9 | 4.763 | 22000 | 26000 | 0.025 |
16003 | 17 | 35 | 8 | 6.8 | 3.35 | 10 | 4.763 | 20000 | 24000 | 0.032 |
16004 | 20 | 42 | 8 | 7.9 | 4.5 | 10 | 5.556 | 18000 | 21000 | 0.051 |
16005 | 25 | 47 | 8 | 8.35 | 5.1 | 12 | 5.556 | 15000 | 18000 | 0.059 |
16006 | 30 | 55 | 9 | 11.2 | 7.4 | 12 | 6.35 | 13000 | 15000 | 0.091 |
16007 | 35 | 62 | 9 | 11.7 | 8.2 | 14 | 6.35 | 12000 | 14000 | 0.107 |
16008 | 40 | 68 | 9 | 12.6 | 9.65 | 15 | 6.35 | 10000 | 12000 | 0.125 |
16009 | 45 | 75 | 10 | 12.9 | 10.5 | 16 | 6.35 | 9200 | 11000 | 0.171 |
16010 | 50 | 80 | 10 | 13.2 | 11.3 | 16 | 7.144 | 8400 | 9800 | 0.18 |
16011 | 55 | 90 | 11 | 18.6 | 15.3 | 16 | 7.938 | 7700 | 9000 | 0.258 |
16012 | 60 | 95 | 11 | 20 | 17.5 | 18 | 7.144 | 7000 | 8300 | 0.283 |
16013 | 65 | 100 | 11 | 20.5 | 18.7 | 20 | 7.144 | 6500 | 7700 | 0.307 |
16014 | 70 | 110 | 13 | 24.4 | 22.6 | 15 | 9.525 | 6100 | 7100 | 0.441 |
16015 | 75 | 115 | 13 | 25 | 24 | 16 | 9.525 | 5700 | 6700 | 0.464 |
16016 | 80 | 125 | 14 | 25.4 | 25.1 | 15 | 11.112 | 5300 | 6200 | 0.597 |
16017 | 85 | 130 | 14 | 25.9 | 26.2 | 16 | 11.112 | 5000 | 5900 | 0.626 |
16018 | 90 | 140 | 16 | 33.5 | 33.5 | 15 | 12.7 | 4700 | 5600 | 0.848 |
. . . |
||||||||||
16052 | 260 | 400 | 44 | 235 | 310 | 1100 | 1500 | 22.5 |
